Stylish Design
Reliable Functions

Motor speed can go up to 33cm/s with 500kg force.
Manual release is available when meeting emergencies.

Modern Design

Quality Guarantee

Safe Operation

Back-up Battery

Manual Release

Easy Installation

Sliding DC Motor Series

Features

Motor Current Detection
-Allows users to monitor the motor operation status through the LED display panel on the control board

High Speed Version
-Motor speed can go up to 33cm/s with 500kg force

Effortless Quick Release Device
-Using specific key to release which is more secure

Built-in Smart Control
-Remotely open and close gates with Chow! App
-Programming the motor through Chow! App
-Secure your house even better with ChowCAM and ChowBELL

Specifications
SpecificationAGs-500 DCAGs-1000 DC
Max Gate Length6M8M
Max Gate Weight500Kg1000Kg
Gear TypeWorm GearWorm Gear
Power Supply110–240VAC (50–60Hz)110–240VAC (50–60Hz)
Motor Power Supply24VDC24VDC
Rated Power 120W160W
Rotation Speed1600 RPM1600 RPM
Manual ReleaseKeyKey

Sliding AC Motor Series

Features

User Friendly Design
-The control panel uses rotary knob for adjusting overcurrent and resistance

Perfect for Heavy gate Application
-AC motor with great force up to 1200Kg output

Advantages
-Innovative and self design control board
-Soft start and Soft stop
-Manual clutch release

Specifications
Specificationags-500AGs-800AGs-1200
Max Gate Length6M8M12M
Max Gate Weight500Kg800Kg1200Kg
Gear TypeWorm GearWorm GearWorm Gear
Power Supply230VAC (50Hz)230VAC (50Hz)230VAC (50Hz)
Motor Power Supply230VAC (50Hz)230VAC (50Hz)230VAC (50Hz)
Rated Power370W550W750W
Enclosure Dimensions246×172×325 mm246×172×325 mm246×172×325 mm
Manual ReleaseKeyKeyKey
